This article compares wafer butterfly valves with traditional gate and globe valves, focusing on installation space, operation speed, cost, and maintenance. It highlights the advantages of wafer designs – compact, lightweight, low pressure drop, and automation‑ready. Tianjin Worlds Valve Co., Ltd. is presented as a reliable OEM/ODM manufacturer offering full material customization, replaceable soft seats, and international certifications (ISO 9001, CE, UKCA, WRAS, ACS, DNV/ABS). The guide helps engineers select the right valve based on media, temperature, pressure, and frequency of operation, with practical tips on seat and body materials.

This article explains how wafer butterfly valves work and their key advantages: space-saving compact structure, lightweight handling, low cost, fast quarter-turn operation, good sealing, and smooth flow control. It also covers material selection and how to choose the right valve from Tianjin Worlds Valve.

A wafer butterfly valve controls flow with a simple 90° rotating disc. This article explains how it works, its main components, compact and lightweight design advantages, common applications in water treatment, HVAC, and chemical systems, plus practical tips for selecting the right seat materials and actuator options for different industrial pipelines.

This 5″ pneumatic wafer butterfly valve features a CF8M stainless steel body and disc, PTFE seat, and split body construction for easy maintenance. Equipped with a double-acting actuator and limit switch for remote position feedback. Rated PN10, temperature range -35°C to +200°C. Suitable for corrosive media including acids, alkalis, and solvents. Fully customizable materials, actuator, and accessories. Manufactured by Tianjin Worlds Valve Co., Ltd., an ISO 9001 certified OEM/ODM supplier offering CE, UKCA, WRAS, and ACS certifications.

This PTFE lined wafer butterfly valve with chainwheel operator allows safe ground‑level control of valves installed high on pipelines. Primary PTFE micropowder and 30KV spark testing ensure lining integrity. Handles aggressive chemicals across a wide temperature range. Fully customizable for your application.

This hand lever wafer butterfly valve features a replaceable soft EPDM seat, allowing field maintenance without pipeline removal. Available 2" to 12" (DN50-DN300) with ductile iron body and CF8 disc. optional gear, electric, or pneumatic actuators. Seat materials (EPDM, NBR, Viton, PTFE) and disc materials fully customizable. Suitable for water, HVAC, mild chemicals, and oil services. ISO 9001 certified OEM manufacturer.

This wafer butterfly valve features a ductile iron body, CF8 disc, and a field-replaceable soft EPDM seat. Available from 2″ to 120″ (DN50-DN3000), it suits water, wastewater, and HVAC applications. All materials are fully customizable, and the replaceable seat reduces maintenance downtime.

This concentric wafer butterfly valve features a ductile iron body, CF8 stainless steel disc, and PTFE seat. The PTFE seat provides outstanding chemical resistance, a wide temperature range (-35℃to +200℃), and low friction operation. The concentric design ensures symmetric sealing, low torque, and bi-directional flow capability. Available DN50-DN600, PN10/PN16/Class 150. Suitable for chemical dosing, water treatment, food processing, and high-purity applications. Disc and seat materials are fully customizable for more aggressive service conditions. Manufactured by Tianjin Worlds Valve Co., Ltd., an ISO 9001 certified OEM supplier.

This product introduces a two-shaft wafer butterfly valve featuring a ductile iron body, CF8 stainless steel disc, EPDM seat, and worm gear operator. The two-shaft design uses independent upper and lower stems, simplifying maintenance and reducing the risk of seizure. The worm gear provides effortless self-locking operation with visual position indication. Available DN50-DN600, PN10/PN16, suitable for water, HVAC, and general industrial services. Disc and seat materials are fully customizable for more aggressive media.

This wafer butterfly valve from Tianjin Worlds Valve Co., Ltd. combines a CF8 (ASTM A351 Grade CF8) stainless steel disc with an NBR rubber seat, built into a ductile iron (GGG40) wafer body. The standard NBR seat performs well in oil, fuel, aliphatic hydrocarbon, and mild chemical media. Beyond this baseline configuration, all major components are fully customizable: disc materials include CF8, CF8M, Duplex 2205, Super Duplex 2507, and Aluminum Bronze; seat materials include EPDM, Viton (FKM), and PTFE. The product covers DN50–DN3000, fits PN10/PN16/Class 150 pipelines, and conforms to ISO 5752 face-to-face dimensions. Suitable for water treatment, oil handling, HVAC, food processing, and general industrial services.
