Design:Electric Butterfly Valve with Double Flanged
Type: CBF01-TF01 OPERATION AND MAINTENANCE MANUAL DOWNLOAD
Size: DN50-DN2000
Body material: DI Carbon steel Stainless Steel Aluminum Bronze...
Seat: EPDM NBR FKM CR NR MVQ CSM...
Disc: CF8M DI Carbon steel Aluminum Bronze...
Stem: SS431
Pressure: 150LB / PN10/16 /JIS10K
Top Flange：ISO 5211 (according to the customer need)
Operating temperatures: -35℃—200℃(depending on pressure, medium and material)
Structure: Double Flanged Design
Operated: Hand Lever, Worm Gear, Electric Actuator, Pneumatic Operated...
This Heavy Duty Electric Butterfly Valve with Double Flanged is designed for critical applications that demand robust construction, reliable automation, and long-term performance under high pressure, high cycle, or harsh environmental conditions. Combining a durable double-flanged body with a precision electric actuator, it provides a complete, maintenance-friendly solution for remote and automated flow control in water, wastewater, power, and industrial processing.
1. Robust Double Flanged Construction
Provides a secure, bolt-through connection to pipeline flanges, ensuring superior leak resistance and mechanical stability under high pressure and vibration.
Ideal for mainline isolation and applications where pipeline integrity is critical.
2. Heavy-Duty Design & Materials
Features an oversized stem, reinforced disc, and high-strength body materials (e.g., ductile iron with epoxy coating, WCB, stainless steel) to withstand demanding service.
Engineered for extended cycle life and reliability in abrasive or corrosive media.
3. Precise Electric Actuation & Smart Control
Equipped with a high-torque electric actuator for accurate positioning, supporting on/off, modulating, and smart control (with optional feedback, BUS communication).
Enables seamless integration into SCADA, PLC, or plant control systems for centralized management.
4. Fail-Safe & Low-Maintenance Operation
Optional fail-safe (spring-return) configurations ensure safe valve position (open/close) upon power loss.
Electric actuation reduces maintenance needs compared to pneumatic systems, with self-diagnostic features available in advanced models.
5. Versatile & Ready for Harsh Environments
Suitable for a wide range of media including water, wastewater, slurries, and mild chemicals.
Actuator housing rated for waterproof, dustproof, and corrosion-resistant operation .
Water & Wastewater Treatment Plants (Pump Control, Mainline Isolation)
Power Generation & Cooling Water Systems
Mining & Mineral Slurry Processing
Chemical & Industrial Process Lines
HVAC for Large Commercial or District Energy Systems
As a specialist actuated valve supplier and manufacturer, Tianjin Worlds Valve Co., Ltd. provides more than just products. We deliver integrated, reliable flow control solutions.
End-to-End Responsibility: We supply the complete assembly—valve, actuator, and controls—ensuring perfect compatibility and single-source accountability.
Custom Engineered Solutions: Offering OEM/ODM services, we customize valve specifications, materials, and actuation packages to meet your exact process requirements.
Proven Quality & Compliance: Our manufacturing process is ISO 9001 certified, with valves tested to relevant standards ( AWWA, EN) for guaranteed performance.
Global Technical Support: From specification to after-sales service, our team provides expert support to ensure optimal valve selection and operation.
Meeting Your Specific Needs:
