Product Name: Lug Butterfly Valve
Body Material: Ductile Iron (DI)
Disc Material: Ductile Iron (DI)
Seat Material: EPDM, NBR, VITON, PTFE...(Seat material options vary depending on the media or customer preference.)
Connection Type: Lug Type
Size Range: DN50–DN2000
Pressure Rating:
PN10 / PN16 / PN25...
Top Flange: Available in ISO 5211 standard for direct actuator mounting
Operating Temperature Range: -20°C to 120°C (EPDM)
Customization: All materials, dimensions, and pressure ratings can be modified according to customer requirements
Type: CBF02-TL01--Product Catalog
1. Lug Body – Bi-Directional Dead-End Service Capability
Threaded lug inserts allow bolted connection to a single flange for end-of-line isolation.
Rated for bi-directional service at full rated pressure, making it ideal for isolation points, system expansion connections, and maintenance shut-offs.
Compatible with ANSI 125# and 150# flanges, EN 1092 PN10/PN16 flanges, and JIS 10K.
2. Ductile Iron Body and Disc – High Strength & Impact Resistance
Both body and disc cast from ductile iron (GGG40/500-7), delivering tensile strength >400 MPa (65 ksi) and excellent elongation (~15%).
Provides high impact resistance and superior ductility compared to gray cast iron.
Epoxy coating (any RAL color, minimum 250μm thickness) provides excellent external corrosion protection.
3. EPDM Seat – Reliable Water Service Sealing
EPDM (ethylene propylene diene monomer) offers bubble-tight shut-off (Class VI) for water, treated water, and mild chemicals.
Excellent resistance to water, steam, ozone, UV, and aging – ideal for outdoor and buried installations.
Temperature range: -20°C to +120°C.
Upgrade options: NBR (for oil/fuel) or Viton (for aggressive chemicals/high temperatures) available upon request.
4. Worm Gear Operator – Smooth, Self-Locking Manual Control
High gear reduction provides effortless operation for 20-inch valves, even under differential pressure.
Self-locking mechanism holds disc at any position without drifting–no mechanical brake required.
Visual position indicator on gear housing allows quick valve status verification.
ISO 5211 top flange enables direct mounting of electric or pneumatic actuators for automated operation.
5. Proven Large-Diameter Design
Gear operation is standard for sizes 12 inches and above – handle operation only available up to 10 inches.
Conforms to MSS SP-67 and API 609 standards.
Dual stem seals prevent external leakage and protect internal components in demanding environments.
6. Fully Customizable OEM/ODM Solution
Disc materials: Ductile iron (standard), CF8, CF8M, duplex, super duplex, aluminum bronze.
Seat materials: EPDM (standard), NBR, Viton, PTFE – replaceable or vulcanized options.
Body materials: Ductile iron (standard), WCB carbon steel, CF8, CF8M.
Pressure ratings: PN10, PN16, Class 150, JIS 10K.
Flange standards: EN 1092-2, ANSI B16.5 Class 150, AS2129, JIS B2220.
Operation: Worm gear (standard), hand lever, electric actuator, pneumatic actuator.
Certifications: ISO 9001, CE, UKCA, WRAS, ACS available upon request.
Direct OEM/ODM Manufacturer – We produce in our own ISO 9001 certified factory, not only a trading company. Every 20-inch lug butterfly valve is manufactured to your exact specifications.
Large-Diameter Expertise – Our manufacturing experience includes valves up to DN1200 (48 inches), with rigorous quality control and testing for large-diameter products.
Proven Material Combinations – Ductile iron body and disc paired with EPDM seat deliver reliable performance for water and municipal applications. For more demanding media, upgrade options (CF8M disc, Viton seat, etc.) are available.
Dead-End Service Capability – The lug design and full rated pressure rating ensure reliable isolation in end-of-line and maintenance shut-off applications.
Certified Quality – ISO 9001 certified with CE, UKCA, WRAS, and ACS certifications available upon request to meet global market requirements.
Full Documentation – Material certificates (mill test reports) and pressure test reports provided with every order.
Global Export Experience – Supplying valves to over 50 countries with reliable logistics and technical support.
We invite you to contact us for a competitive quotation or to arrange a visit to our factory. Our engineering team is ready to discuss your specific media, temperature, and pressure requirements – whether you need a standard 20-inch PN16 lug butterfly valve or a fully customized solution with special materials or actuation.
