Rubber Seat & SS Disc Ductile Iron Wafer Butterfly Valve | Cost-Effective Industrial Solution
Tianjin Worlds Valve Co., Ltd. – ISO 9001, CE, UKCA & WRAS Certified Manufacturer
CBF02-TA01-Operation and Maintenance Manual DOWNLOAD
Material Reliability: EN-GJS-400-18 ductile iron offers excellent mechanical strength and impact resistance
Outstanding Corrosion Resistance: Ductile iron naturally forms a protective patina layer that inhibits rust, providing excellent corrosion resistance, particularly in water and wastewater applications. For more aggressive media, its properties can be significantly enhanced with various standard linings (such as epoxy) or coatings, making it suitable for a wide range of corrosive fluids.
Excellent Cost-Effectiveness and Castability：Ductile iron is a highly cost-effective material solution. It provides mechanical properties close to carbon steel but at a lower overall cost.
Corrosion Resistance: 316 stainless steel disc ensures longevity in water and mild chemical services
Surface Precision: Precision-machined disc surface guarantees perfect seating alignment
Durability: Maintains structural integrity under pressure and temperature variations
Bubble-Tight Sealing: EPDM/NBR seats achieve zero leakage per EN 12266-1 Class A standards
Temperature Adaptability: Suitable for applications from -20°C to 120°C
Chemical Compatibility: Multiple rubber materials available for different media requirements
Space Optimization: Compact design reduces installation space requirements by 40%
Easy Installation: Simple insertion between ANSI/DIN flanges without additional hardware
Weight Reduction: 35% lighter than lug-type valves of similar size
Parameter | Specification |
Model | CBF02-TA01 |
Sizes | DN50-DN1200 |
Pressure Class | PN6/10/16/150LB/JIS10K/AS “D”/ “E” |
Design | EN593 BS5155 EN1092 ISO5211 |
Testing | ISO5208 EN12266-1 |
TOP Flange | ISO5211 (according to customer’s needs) |
Face to Face | EN558-1 DIN3202 ISO5752 BS5155 |
Standard | ASME B16.34 |
Body | Ductile Iron |
Disc | CF8M |
Seat | EPDM |
Stem | SS431 |
Optimal Value: Ductile iron body with stainless steel disc provides excellent performance at competitive pricing
Reliable Sealing: Rubber seats ensure bubble-tight shutoff for various fluid applications
Space Efficiency: Wafer design saves installation space and reduces overall project costs
Global Compliance: CE, UKCA, and WRAS certifications ensure international market acceptance
Low Maintenance: Durable materials and precision engineering minimize service requirements
Customization Options: Available in special sizes, coatings, and configurations for OEM projects
Water Treatment Systems: Distribution networks, filtration units, and pumping stations
HVAC Services: Chilled water circuits, cooling towers, and air handling systems
Industrial Processing: Cooling water lines, process fluid control, and utility services
Fire Protection: Sprinkler systems and hydrant supply lines
Building Services: Plumbing systems and mechanical equipment rooms
Irrigation Systems: Agricultural and landscape watering networks
Combining ductile iron reliability with stainless steel durability and rubber seat performance, this wafer butterfly valve delivers exceptional value for water treatment, HVAC, and industrial applications requiring cost-effective flow control solutions.
