Design:Electric Actuator Double Flanged Butterfly Valve
Type: CBF01-TF01 OPERATION AND MAINTENANCE DOWNLOAD
Size: DN150
Body material: DI (Ductile Iron)
Seat: EPDM (Vulcanized Rubber Seat)
Disc: CF8M
Pressure rating: PN16
Operating temperatures: -20℃—120℃(depending on pressure, medium and material)
Structure: Flange Type
The Electric Actuator Double Flanged Butterfly Valve integrates robust flanged construction with precise electric actuation to deliver reliable automated flow control in demanding industrial applications. This complete package solution ensures optimal performance in water treatment, HVAC, chemical processing, and other automated systems requiring remote operation and precise modulation.
1. Precise Electric Actuation
Enables accurate position control and programmable operation
Supports 4-20mA control signals for seamless PLC/DCS integration
Provides fail-safe options for critical application requirements
2. Robust Double Flanged Design
Ensures secure pipeline connection with ANSI/DIN standard flanges
Eliminates potential leakage points compared to wafer-style valves
Withstands higher pressure ratings and mechanical stress
3. Bubble-Tight Sealing Performance
Maintains zero leakage in both flow directions
Compatible with various seat materials (EPDM, Viton, PTFE)
Suitable for both isolation and regulating duties
4. Low Maintenance Operation
Electric actuators require minimal maintenance compared to pneumatic systems
Self-lubricating bearings ensure smooth operation over extended periods
Corrosion-resistant materials extend service life in harsh environments
5. Energy Efficient Solution
Consumes power only during position changes
No continuous air supply required
Optional power-saving modes available
Water and Wastewater Treatment Plants
HVAC and Building Automation Systems
Chemical and Pharmaceutical Processing
Power Generation and Distribution
Industrial Process Automation
Customizable seat and lining materials
Full compliance with international standards
OEM/ODM support with third-party certification support
Global supply capability with after-sales technical service
Manufactured under ISO 9001 quality standards with complete testing documentation. Available with customized actuation solutions and third-party certification support to meet specific project requirements.
