Lug Butterfly Valve–PN16, Aluminum Handle, OEM Manufacturer

Product Overview

A lug butterfly valve is a quarter-turn flow control device distinguished by its threaded lug design–threaded inserts on both sides of the valve body that allow it to be bolted directly to pipe flanges independently on each side.

Unlike wafer valves that are sandwiched between flanges and require full disconnection for removal, the lug design enables dead-end service: you can remove the valve from one side of the pipeline while the other side remains pressurized and operational. This makes it the preferred choice for systems where maintenance isolation, pipeline flexibility, and reduced downtime are critical.

This model features a DI (ductile iron) body for strength and durability, a CF8M stainless steel disc for superior corrosion resistance, an EPDM seat for reliable sealing, and an aluminum handle for lightweight, smooth manual operation–rated at PN16 (16 bar) . The aluminum handle reduces overall valve weight and provides comfortable, ergonomic operation without the corrosion concerns of traditional cast iron handles.

As a direct OEM/ODM manufacturer with over 19 years of export experience, Tianjin Worlds Valve Co., Ltd. delivers fully customizable lug butterfly valves–materials, sizes, pressure ratings, flange standards, coatings, and actuators–all tailored to your exact specifications. Our products are exported to more than 50 countries and backed by ISO 9001 (certified by LRQA), CE, UKCA, WRAS, and ACS certifications.

Introduce:

Lug Butterfly Valve | Ductile Iron Body | CF8M Disc | Aluminum Handle | PN16 | OEM Manufacturer

Tianjin Worlds Valve Co., Ltd.–Your Reliable Source for Durable, Cost-Effective Flow Control

CBF02-TL01 - Detailed Product Info

Technical Specifications

This model is configured with the following parameters. Please note that every item listed below is customizable to your specific needs.

Key Features & Advantages

1. Lug Type Design–Dead-End Service & Maintenance Isolation

• Independent Pipeline Mounting–Threaded lugs on both sides of the valve body allow each side to be bolted independently to pipe flanges, enabling dead-end service–the valve can be installed at the end of a pipeline or used to isolate a section for maintenance.

• Simplified Maintenance–The valve can be removed from one side without depressurizing or shutting down the entire pipeline–a critical advantage in plants where downtime is costly.

• Superior Rigidity–The lug design provides greater structural strength than wafer types, withstanding pipe stress, vibration, and thermal expansion.

• Bidirectional Sealing–Provides reliable shut-off in both flow directions.

2. Body Material–Ductile Iron (GGG40 / 500-7)

• High Strength–Offers tensile strength of ≥400 MPa and yield strength of ≥250 MPa, providing reliable performance under PN16 pressure surges.

• Excellent Impact Resistance–The nodular graphite structure delivers exceptional toughness, withstanding mechanical shock and pipeline vibration without fracturing.

• Corrosion Protection–Combined with standard epoxy coating (250μm minimum), the body resists corrosion in water, wastewater, and general industrial service.

3. Disc Material–CF8M Stainless Steel (AISI 316)

• Superior Corrosion Resistance–CF8M offers excellent resistance to pitting and crevice corrosion, particularly in chloride environments, seawater, and aggressive media.

• Wide Chemical Compatibility–Suitable for water, wastewater, mild chemicals, acids, and alkalis.

• Long Service Life–The corrosion-resistant properties of CF8M ensure extended service life even in aggressive environments, reducing replacement frequency and maintenance costs.

4. Seat Material–EPDM

• Excellent Water Resistance–EPDM offers outstanding resistance to water, steam, and outdoor weathering, making it ideal for water supply, wastewater, and HVAC applications.

• Good Chemical Resistance–Resists dilute acids, alkalis, and a wide range of water treatment chemicals including chlorine and ozone.

• Wide Temperature Range–Maintains sealing properties from -20°C to +120°C.

• Bubble-Tight Shut-Off–Provides reliable bi-directional sealing, ensuring zero leakage in both flow directions.

5. Aluminum Handle–Lightweight & Ergonomic

• Reduced Weight–Aluminum is significantly lighter than cast iron or ductile iron handles, reducing overall valve weight and making installation and operation easier.

• Corrosion Resistant–Aluminum naturally forms a protective oxide layer that resists corrosion, making it suitable for outdoor and humid environments.

• Ergonomic Design–The smooth surface and balanced design provide comfortable grip and easy operation, even after extended use.

• Locking Plate Included–The handle features a locking plate for position locking, preventing accidental operation and ensuring safe maintenance.

6. ISO 5211 Top Flange–Ready for Automation

All our lug butterfly valves feature a standard ISO 5211 top flange, providing universal interchangeability for various actuation methods:

• Hand Lever–Quick manual on-off control with locking plate (standard for this model)

• Gear Operator–Self-locking with open-close indicator (larger sizes)

• Electric Actuators–On-off or modulating types with 4-20 mA feedback

• Pneumatic Actuators–Double-acting or spring-return (fail-safe) designs

• Hydraulic Actuators–High-torque, subsea, or explosive environments

Typical Applications

Lug butterfly valves with DI body, CF8M disc, EPDM seat, and aluminum handle are trusted across a wide range of industries:

• Water Supply & Distribution–Municipal water mains, pumping stations, distribution networks.

• Wastewater Treatment–Sewage lines, treatment plants, effluent systems.

• HVAC Systems–Chilled water, hot water, cooling tower systems .

• Industrial Processing–General industrial water lines, cooling water, process fluids.

• Fire Protection–Fire water lines, sprinkler systems, deluge systems.

• Irrigation–Agricultural and landscape irrigation systems.

Why Choose Tianjin Worlds Valve?

• Quality you can trust. Our ISO 9001:2015 certification is issued by LRQA, one of the world's most respected certification bodies. Every valve comes with material certificates and pressure test reports–no exceptions.

• Lug Valve Specialists. We have extensive experience manufacturing lug butterfly valves for water, industrial, and municipal projects worldwide.

• Aluminum Handle Advantage. Our aluminum handles reduce valve weight and resist corrosion–ideal for outdoor installations and applications where weight matters.

• Full Customization. Materials, sizes, pressure ratings, flange standards (ANSI, DIN, JIS, BS), coatings (any RAL color), actuators–all to your specification.

• 19+ Years Export Experience. Smooth logistics and after-sales support to 50+ countries across Europe, Americas, Middle East, and Southeast Asia.

• 100% Traceability. Material certificates and pressure test reports with every order–no exceptions.

• Quick Turnaround. Dedicated project manager; typical lead time 15–40 days. Factory visits welcome in Tianjin.

Get in Touch–Customize Your Lug Valve Today:

Whether you need this PN16 configuration with aluminum handle, a different size, automated actuation, or a complete valve package for a large-scale project – we're ready to build to your specification.

Send us your requirements:

• Required size and pressure rating

• Media type and operating temperature

• Preferred material combination (body / disc / seat)

• Actuator type (manual, gear, electric, pneumatic, hydraulic)

• Flange standard and drilling (ANSI, DIN, JIS, BS)

• Coating color (any RAL)

• Target quantity and destination port

Our team will respond within 24 hours with a quotation and engineering proposal.

Factory visits welcome – come see how we manufacture your valves in Tianjin, China.

Contact Us Now and Let's Build Your Valve Together.
