Hard Back Seat SS Wafer Butterfly Valve with Polishing Disc | Metal-Seated High-Temperature Solution
Tianjin Worlds Valve Co., Ltd. – Your Trusted ISO 9001 Certified Manufacturing Partner
CBF02-TA01-Operation and Maintenance Manual DOWNLOAD
1. Precision Polished Disc Surface
Mirror Finish: Ra ≤ 0.4μm surface finish minimizes friction and prevents particle adhesion
Enhanced Durability: hard-facing on disc edge for abrasion resistance
Corrosion Resistance: 316L/316SS disc with optional super duplex 2507 for chloride environments
2. Wafer Space-Saving Design
Compact Construction: 40% lighter than lug-type valves with identical pressure rating
Easy Installation: Fits between ANSI B16.5 or DIN EN 1092-1 flanges
Cost Efficiency: Reduced material and installation costs
3. Operational Excellence
Long Service Life: 100,000+ cycles in abrasive service conditions
Multiple Actuation Options: Compatible with manual lever, gear operator, or ISO 5211 standard actuators.
Visual Position Indication: Clear open/close status for operational safety and convenience.
4. SS Valve Body Advantages
Superior Corrosion Resistance：SS valve bodies (typically 304/316 stainless steel) demonstrate exceptional resistance to chemical corrosion, oxidation, and pitting, particularly in chloride-rich environments. This extends valve service life by 3-5× compared to carbon steel in aggressive media like seawater, acids, and chemical processing fluids, while eliminating external coating requirements.
Hygienic & Low Maintenance：With electropolishing capability (Ra≤0.8μm) and non-porous surfaces, SS bodies prevent bacterial growth and particle adhesion, meeting FDA/USP Class VI standards for pharmaceutical and food applications. The material's inherent durability eliminates corrosion-related maintenance while enabling full CIP/SIP cleaning compatibility.
5. Quality Assurance & Compliance
ISO 9001 Certified Manufacturing: Ensures consistent quality control throughout production process
International Certifications: CE, UKCA, and WRAS approvals guarantee compliance with global market requirements
Material Traceability: Full documentation and material certifications available for quality verification
Parameter | Specification |
Model | CBF02-TA01 |
Sizes | DN50-DN1200 |
Pressure Class | PN6/10/16/150LB/5K/10K/AS “D”/ “E” |
Design | EN593 API 609 BS5155 EN1092 ISO5211 |
Testing | API598 ISO5208 EN12266-1 |
TOP Flange | ISO5211 (according to customer’s needs) |
Face to Face | EN558-1 API609 DIN3202 ISO5752 BS5155 |
Power Generation: Steam lines, turbine bypass, and boiler feed systems
Oil & Gas: Pipeline isolation, wellhead control, and refinery processing
Chemical Processing: High-temperature reactors, catalyst handling, and abrasive slurry
Petrochemical: Ethylene cracking furnaces, reformer units, and hydroprocessing
Metallurgical: Hot air/gas handling, furnace systems, and dust collection
Marine: Engine room ventilation, exhaust systems, and fire safety
Extreme Temperature Capability: Reliable performance from cryogenic to high-temperature services
Abrasion Resistance: Hard-faced seating surfaces withstand particulate-laden media
Zero Maintenance: Permanent metal seats eliminate replacement needs
Fire Safety: Certified for emergency shutdown in hydrocarbon fire scenarios
Global Compliance: CE, UKCA, and API certifications for international projects
Custom Engineering: Special materials, coatings, and trim configurations available
Specifically engineered for extreme temperatures and abrasive services, this hard back seat SS wafer butterfly valve with polishing disc delivers unmatched reliability where soft-seated valves would fail.
