Tianjin Worlds Valve Co., Ltd. engineers Extended Stem Lug & Tapped Butterfly Valves with Hand Lever Actuation for rapid isolation in confined or elevated installations. Combining a threaded lug body, extended ISO 5211-compliant stem, and manual lever operation, these valves enable direct pipeline mounting without nuts while providing visual position indication. Certified to WRAS, ISO 9001, and CE-PED,UKCA,ACS they serve HVAC, shipbuilding, and industrial systems requiring space-efficient, maintenance-free flow control.

Model:
CBF01-TL01
Brand:
OEM|ODM

Quantity:
Availability:





Inquire Add to Basket

Product Description

Introduction：

Extended Stem Lug & Tapped Butterfly Valve with Hand Lever Actuation | Direct-Mount Isolation Solution

Tianjin Worlds Valve Co., Ltd. – ISO 9001 Certified Manufacturer

CBF01-TL01-Operation and Maintenance Manual download Extended Stem Lug & Tapped Butterfly Valve with Hand Lever Actuation Direct-Mount Isolation-1 (1)

Key Features:

1. Threaded Lug Body with Tapped Holes

Direct bolt-to-body mounting eliminates nuts, reducing installation time by 40% vs. standard lug valves.

Class 150 tapped holes prevent thread stripping during thermal cycling.

2.Extended Stem for Accessibility

stem extensions position hand lever above insulation/obstacles, compliant with ISO 5211 height standards.

sealed stem bushing prevents grit ingress in dusty/marine environments.

3. Low-Torque Hand Lever Actuation

Forged stainless steel lever (304 SS) with 4:1 mechanical advantage reduces operating force to ≤50 Nm at PN16 pressures.

4. Zero-Leakage EPDM/PTFE Sealing

Double-offset EPDM seat achieves EN 12266-1 Class A shutoff (tested at 1.1x PN16).

Optional PTFE seat for chemical resistance (-20°C to 200°C).

5. Corrosion Defense System

Body: Ductile iron with 250µm epoxy coating.

Disc:You can choose 316L stainless steel with a surface that has undergone electropolishing, which has strong corrosion resistance.

Technical Parameters：

Size	DN32-DN600	DN650-DN2000
Working pressure	16Bar	10Bar
Shell	24Bar	15Bar
Seal	18Bar	11Bar
Operating Temperature	-45℃~+150℃
Operating Environment	Ballast and bilge system Chemical processing Desalination plants Drilling rigs Drinking water Dry powder Food and beverage Gas plants HAVC Mining industry Paper industry Sand handling Seawater Sugar industry Thermo technical water treatment Waste water
Driving method	Hand Lever Worm Gear Electric Pneumatic

Extended-Stem-Lug-&-Tapped-Butterfly-Valve-with-Hand-Lever-Actuation--Direct-Mount-Isolation-2-(3)

Main Material:

Name	Material
Body	Cast Iron Ductile Iron Carbon Steel Stainless Steel AL-Bronze
Disc	Ductile Iron Carbon Steel Stainless Steel AL-Bronze
Shaft	Stainless Steel Monel K500
Seat	BUNA NBR EPDM VITON PTFE HEPDM Neoprene Hypalon Natural rubber

Extended-Stem-Lug-&-Tapped-Butterfly-Valve-with-Hand-Lever-Actuation--Direct-Mount-Isolation-2-(1)

Industry-Specific Applications

These Extended Stem Lug & Tapped Butterfly Valves are engineered for precision control in demanding environments:

HVAC Systems: Isolate chilled water lines with visible lever positioning above insulation layers.

Marine/Shipbuilding: Saltwater-resistant epoxy coating withstands offshore corrosion (DNV-GL certified options).

Food & Beverage: FDA-compliant PTFE seats enable rapid CIP/SIP cleaning without disassembly.

Water Treatment: NSF/ANSI 61-certified EPDM seats for safe potable water shutoff.

Industrial Piping: Threaded lug design simplifies maintenance in cramped pump rooms or elevated racks.

Extended-Stem-Lug-&-Tapped-Butterfly-Valve-with-Hand-Lever-Actuation--Direct-Mount-Isolation-2-(2)

Conclusion:

Discover high-quality Resilient Seated extended stem lug &tapped butterfly valves from a trusted Butterfly Valve Manufacturer. ISO certified, customizable, and built for durability. Ready to enhance your operations with top-quality Pneumatic Operated Butterfly Valves? Contact us today for a free quote or to discuss your custom requirements!

Extended stem lug butterfly valve hand lever Tapped hole direct mount butterfly valve ISO 5211 extended stem industrial valve Space saving lug type butterfly valve EPDM seat PN16 manual butterfly valve HVAC compact isolation valve Lug TYPE BUTTERFLY VALVE OEM customized stem extension valve ISO 9001 certified valve manufacturer Butterfly Valve with Hand Lever Actuation
